CAST CONNEX High Integrity Blocks® structural elements are specially engineered and manufactured solid steel sections which simplify the design and fabrication of – and provide unparalleled strength, quality, and reliability in heavily loaded structural connections.
Pre-engineered and Available off the shelf
Vastly Simplifies Fabrication Efforts
Eliminates Field Welding
Type B
Fits a range of HSS and Pipe
Provides High Quality AESS Connection with Limited Additional Craftsmanship
Designed for use in Seismic Force Resisting Systems

Download Data Sheets

No items found.

Get Access

By creating an Account on our service, you agree to subscribe to newsletters, marketing or promotional materials and other information we may send. However, you may opt out.

  • Specification Guidelines

  • CAD Files

  • Installation Guides

  • Etc


Heading 1

Heading 2

Heading 3

Heading 4

Heading 5
Heading 6

Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. Ut enim ad minim veniam, quis nostrud exercitation ullamco laboris nisi ut aliquip ex ea commodo consequat. Duis aute irure dolor in reprehenderit in voluptate velit esse cillum dolore eu fugiat nulla pariatur.

Block quote

Ordered list

  1. Item 1
  2. Item 2
  3. Item 3

Unordered list

  • Item A
  • Item B
  • Item C

Text link

Bold text




This is a test headline

As a result of intensive research and development paired with careful engineering and manufacturing control, CAST CONNEX is able to design and deliver ultra-heavy, weldable structural steel sections (up to 4-foot x 4-foot cross sections, and up to fifty feet in length depending upon cross-sectional dimensions) which exhibit up to 65 ksi (450 MPa) yield strength and elevated Charpy V-Notch (CVN) toughness in all three directions of loading and through the full cross-section.

This is a test headline

Our ability to guarantee through thickness mechanical properties in our High Integrity Blocks products is just as unique in the market as is our material's enhanced resistance to ductile fracture. In particular, High Integrity Blocks structural elements feature a low Carbon Content and an elevated CVN Toughness - two critical factors in enabling structural steel materials to resist fracture in the presence of high triaxiality (Kanvinde and Deierlein, 2006).

Multi-Axis Loads

Because of the way they are engineered and processed, High Integrity Blocks products are also insusceptible to lamellar tearing. As such, High Integrity Blocks structural elements are ideal for use within the center of multi-axis loaded structural connections where lamellar tearing of hot rolled plate may compromise quality and strength of the connection or where the lamination of multiple steel plates to build up a solid section is not advisable due to the need to transmit forces orthogonal to the laminations.

As High Integrity Blocks structural elements are engineered products (not just a material!), we encourage designers interested in their use to contact us during the design phases of the project for design and specification support.

We provide design-build services

CAST CONNEX specializes in the engineering and provision of cast steel components for building and bridge structures.
